Professional tradespeople cannot afford downtime. For decades, power tool manufacturers understood that their products needed to be field-repairable. They provided detailed exploded-view diagrams in manuals and made brushes, triggers, and chucks readily available.

The Shift to Brushless and Digital

As the industry transitions from brushed DC motors to electronically controlled brushless systems, the right to repair is under threat. The motors themselves are incredibly durable, but the digital control boards driving them are sensitive black boxes. If a control board fails, manufacturers rarely provide the schematics necessary for board-level repair.

Why Schematics Matter

A schematic is the map to a device's soul. Without it, diagnosing a fault on a printed circuit board requires reverse-engineering the entire circuit—a task beyond most independent repair shops, let alone home DIYers. By locking away these documents, companies artificially monopolize the repair market.

Our top-scoring power equipment brands are those that treat the owner as a capable partner:

• They provide high-resolution exploded diagrams on their websites.
• They standardize internal hardware (using standard Torx or Phillips screws).
• They do not use epoxy to pot control boards, allowing for component-level soldering.

We believe that if a company trusts you enough to operate a high-torque angle grinder, they should trust you enough to sell you the switch when it breaks.
